Eco-Worthy 5000W Complete Off-grid Solar Power Kit | 2340W PV Input | 120V AC Single Phase Output | 5.12kWh Battery Capacity
Eco-Worthy 5000W Complete Off-grid Solar Power Kit
Package Includes:
2340W PV&5.12kWh Battery
12x Bifacial 195W Mono Solar Panels
1x 5000W 48V off-grid solar charger inverter
1x 5M 8AWG Extension Cable with MC4
1x 5M 12AWG Solar Cable with MC4
12x Z Mounting Brackets
1x 48V 100Ah Rack LiFePO4 Lithium Battery
Bifacial 195W Monocrystalline Solar Panel
| Rated Power: 195W | Solar Cell: Monocrystalline |
| Maximum/Peak Voltage(Vmp): 19.8V | Open Circuit Voltage(Voc): 23.7V |
| Short circuit current: 10.5A | Maximum current: 9.85A |
| Output Tolerance: ±3% | Temperature coefficient of Isc: (010+/-0.01)%/℃ |
| Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ | Temperature range: －40℃～ +85℃ |
| Frame: Aluminum alloy frame | Weight: 20.48 lbs(9.29 kg) |
| Size: 52.6x26.38x1.38in (1335*670*35mm) |
5000W 48V Solar Hybrid Inverter Charger
| PV Charging Mode | |
| Max Input Power: 5000W | PV Charging Current Range：0-80A(can be set) |
| Max PV Open Circuit Voltage: 500VDC | PV Operating Voltage Range: 120-450VDC |
| MPPT Voltage Range: 120-450VDC | Battery Voltage Range: 40-60VDC |
| Max Output Power: 5000W | Charging Short Circuit Protection: Blown fuse |
| Rated Output: 120VAC | Rated Battery Input Voltage: 48V |
| Peak Power: 10000W |
48V 100Ah Rack LiFePO4 Lithium Battery
| Battery Capacity: 100Ah | Battery Power: 5120Wh |
| Rated Voltage: 51.2V | Voltage Range: 40~58V |
| Maximum Charge/ Discharge Current: 100A | Charge Temperature Range: 0-55℃ |
| Discharge Temperature Range:﹣20－55℃ | Maximum Charge Voltage: 58.4V |
| Screw size: M8 | Battery Size: 52.27*43.51*14.3cm (22.55*17.13*5.63inch) |
| Battery Weight: 44kg(97 lbs) | Each battery comes with a pair of battery parallel cables |
5M 12AWG Solar Cable Wires with MC4
| Cable Type: Connecting Solar Panels to Charge Controllers | Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） | Conductor: Tinned copper wire |
| AWG: 12 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
| Connector: MC4 |
5M 8AWG Solar Extension Cable Wires with MC4-MC4
| Cable Type: Connecting Solar Panel to Solar Panel In Parallel | Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） | Conductor: Tinned copper wire |
| AWG: 12 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
| Connector: MC4 |
Z Mounting Brackets
| 12 pieces of Z-shaped solar panel brackets |
Eco-Worthy 5000W Complete Off-grid Solar Power Kit
Package Includes:
2340W PV&5.12kWh Battery
12x Bifacial 195W Mono Solar Panels
1x 5000W 48V off-grid solar charger inverter
1x 5M 8AWG Extension Cable with MC4
1x 5M 12AWG Solar Cable with MC4
12x Z Mounting Brackets
1x 48V 100Ah Rack LiFePO4 Lithium Battery
Bifacial 195W Monocrystalline Solar Panel
| Rated Power: 195W | Solar Cell: Monocrystalline |
| Maximum/Peak Voltage(Vmp): 19.8V | Open Circuit Voltage(Voc): 23.7V |
| Short circuit current: 10.5A | Maximum current: 9.85A |
| Output Tolerance: ±3% | Temperature coefficient of Isc: (010+/-0.01)%/℃ |
| Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ | Temperature range: －40℃～ +85℃ |
| Frame: Aluminum alloy frame | Weight: 20.48 lbs(9.29 kg) |
| Size: 52.6x26.38x1.38in (1335*670*35mm) |
5000W 48V Solar Hybrid Inverter Charger
| PV Charging Mode | |
| Max Input Power: 5000W | PV Charging Current Range：0-80A(can be set) |
| Max PV Open Circuit Voltage: 500VDC | PV Operating Voltage Range: 120-450VDC |
| MPPT Voltage Range: 120-450VDC | Battery Voltage Range: 40-60VDC |
| Max Output Power: 5000W | Charging Short Circuit Protection: Blown fuse |
| Rated Output: 120VAC | Rated Battery Input Voltage: 48V |
| Peak Power: 10000W |
48V 100Ah Rack LiFePO4 Lithium Battery
| Battery Capacity: 100Ah | Battery Power: 5120Wh |
| Rated Voltage: 51.2V | Voltage Range: 40~58V |
| Maximum Charge/ Discharge Current: 100A | Charge Temperature Range: 0-55℃ |
| Discharge Temperature Range:﹣20－55℃ | Maximum Charge Voltage: 58.4V |
| Screw size: M8 | Battery Size: 52.27*43.51*14.3cm (22.55*17.13*5.63inch) |
| Battery Weight: 44kg(97 lbs) | Each battery comes with a pair of battery parallel cables |
5M 12AWG Solar Cable Wires with MC4
| Cable Type: Connecting Solar Panels to Charge Controllers | Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） | Conductor: Tinned copper wire |
| AWG: 12 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
| Connector: MC4 |
5M 8AWG Solar Extension Cable Wires with MC4-MC4
| Cable Type: Connecting Solar Panel to Solar Panel In Parallel | Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） | Conductor: Tinned copper wire |
| AWG: 12 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
| Connector: MC4 |
Z Mounting Brackets
| 12 pieces of Z-shaped solar panel brackets |
Original: $3,426.73
-65%$3,426.73
$1,199.36Description
Eco-Worthy 5000W Complete Off-grid Solar Power Kit
Package Includes:
2340W PV&5.12kWh Battery
12x Bifacial 195W Mono Solar Panels
1x 5000W 48V off-grid solar charger inverter
1x 5M 8AWG Extension Cable with MC4
1x 5M 12AWG Solar Cable with MC4
12x Z Mounting Brackets
1x 48V 100Ah Rack LiFePO4 Lithium Battery
Bifacial 195W Monocrystalline Solar Panel
| Rated Power: 195W | Solar Cell: Monocrystalline |
| Maximum/Peak Voltage(Vmp): 19.8V | Open Circuit Voltage(Voc): 23.7V |
| Short circuit current: 10.5A | Maximum current: 9.85A |
| Output Tolerance: ±3% | Temperature coefficient of Isc: (010+/-0.01)%/℃ |
| Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ | Temperature range: －40℃～ +85℃ |
| Frame: Aluminum alloy frame | Weight: 20.48 lbs(9.29 kg) |
| Size: 52.6x26.38x1.38in (1335*670*35mm) |
5000W 48V Solar Hybrid Inverter Charger
| PV Charging Mode | |
| Max Input Power: 5000W | PV Charging Current Range：0-80A(can be set) |
| Max PV Open Circuit Voltage: 500VDC | PV Operating Voltage Range: 120-450VDC |
| MPPT Voltage Range: 120-450VDC | Battery Voltage Range: 40-60VDC |
| Max Output Power: 5000W | Charging Short Circuit Protection: Blown fuse |
| Rated Output: 120VAC | Rated Battery Input Voltage: 48V |
| Peak Power: 10000W |
48V 100Ah Rack LiFePO4 Lithium Battery
| Battery Capacity: 100Ah | Battery Power: 5120Wh |
| Rated Voltage: 51.2V | Voltage Range: 40~58V |
| Maximum Charge/ Discharge Current: 100A | Charge Temperature Range: 0-55℃ |
| Discharge Temperature Range:﹣20－55℃ | Maximum Charge Voltage: 58.4V |
| Screw size: M8 | Battery Size: 52.27*43.51*14.3cm (22.55*17.13*5.63inch) |
| Battery Weight: 44kg(97 lbs) | Each battery comes with a pair of battery parallel cables |
5M 12AWG Solar Cable Wires with MC4
| Cable Type: Connecting Solar Panels to Charge Controllers | Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） | Conductor: Tinned copper wire |
| AWG: 12 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
| Connector: MC4 |
5M 8AWG Solar Extension Cable Wires with MC4-MC4
| Cable Type: Connecting Solar Panel to Solar Panel In Parallel | Rating Voltage: 600/1000V |
| Length: 5 meters（16 ft） | Conductor: Tinned copper wire |
| AWG: 12 | Normal Cross Sectional Area of the Conductor (mm2): 4 |
| Waterproof: IP 65 Protection | Temperature: -40°F to +185°F |
| Connector: MC4 |
Z Mounting Brackets
| 12 pieces of Z-shaped solar panel brackets |
